| Processor | CPU | Supports 12/13/14th Generation Intel® Core Processors (LGA1700) |
| Chipset | Intel H610 /Q670 /B760 chipset | |
| BIOS | AMI EFI 64 Mbit | |
| Memory | Type | 2*DDR4-2933/2666/2400MHz SO-DIMM |
| Max. Capacity | 64 GB | |
| Display | GPU | MXM Graphic Card |
| DP 1.2 | Max. 4096 x 2160 @60Hz | |
| HDMI 2.0 | Max. 3840 x 2160 @60Hz | |
| Audio | Controller | Realtek ALC662 HD |
| Interface | Audio out + Mic in | |
| Ethernet | Controller | 1* Intel i219LM + 1*Realtek RTL8111H, Gigabit Ethernet, Wake-on-LAN support |
| Storage | M.2 2280 | Support SATA / PCIe4x SSD |
| Rear Panel | DP 1.2 | 1 |
| HDMI 2.0 | 1 | |
| USB3.2 | 2 | |
| Audio | Audio out， Mic in | |
| LAN | 2 | |
| COM | 1 (optional) | |
| DC-IN | 1 | |
| Front Panel | Power Button | 1 |
| SSD LED | 1 | |
| USB2.0 | 4 | |
| Expansion | M.2 2230 | Support Wi-Fi /BT |
| M.2 2280 | Support SATA / PCIe4x SSD | |
| MXM | Support MXM graphic card | |
| OS | Windows 10, Linux | |
| Functions | Watchdog, Auto Power On | |
| Power | Power Type | DC-IN (7.4*5.0mm with pin) |
| Adapter | 19V | |
| Cooling | Fan | |
| Dimension | Construction | Metal |
| Mounting | YES | |
| W x H x D | 280 x 177 x 43 mm | |
| Environment | Operating Temp | 0~40℃ |
| Storage Temp | -20~60℃ | |
| Relative Humidity | 95%@40℃ (non-condensing) |
