| Processor | CPU | 125U | 135U | 165U |
| Frequency | 4.3GHz | 4.4GHz | 4.9GHz | |
| Core | 2+8+2 | 2+8+2 | 2+8+2 | |
| Cache | 12MB | 12MB | 12MB | |
| BIOS | AMI EFI 128 Mbit | |||
| Memory | Type | 2*DDR5-4800MHz SO-DIMMs | ||
| Max. Capacity | 64 GB | |||
| Display | GPU | Intel® UHD Graphics / Iris XE (based on CPU) | ||
| HDMI2.1 | 1xHDMI2.1, Max. 7680 x 4320 @60Hz | |||
| HDMI2.0 | 3xHDMI2.0, Max. 3840 x 2160 @60Hz | |||
| HDMI-IN | 2xHDMI-IN （based on CPU with IPU) | |||
| Audio | Controller | CMedia CM119B | ||
| Interface | Audio out + Mic in | |||
| Ethernet | Controller | Intel i219LM & intel 226V, 2.5 Gigabit Ethernet, Wake-on-LAN support , AMT support | ||
| Storage | M.2 | 3 * M.2 2280 with PCIe 4X/ SATA SSD support | ||
| SATA3.0 | 1 | |||
| Rear Panel | HDMI2.1 | 1 | ||
| HDMI2.0 | 3 | |||
| USB2.0 | 2 | |||
| USB3.2 | 2 | |||
| LAN | 2 | |||
| DC-IN | 1 | |||
| Front Panel | Audio Out | 1 | ||
| Mic In | 1 | |||
| USB3.2 | 2 | |||
| USB2.0 | 2 | |||
| Type-C (USB3.2) | 1 | |||
| Right Panel | COM | 1 x RS232 / RS485 | ||
| HDMI-IN | 2 | |||
| Expansion | M.2 #1 | 1 x M.2 2230 with Wi-Fi /BT module support | ||
| M.2 #2 | 1 x M.2 3052 with 4G/5G module support | |||
| M.2 #3,4,5 | 3 * M.2 2280 with PCIe 4X /SATA SSD support | |||
| OS | Windows 10/11 64Bit, Linux | |||
| Functions | Watchdog, Auto Power On, TPM2.0 | |||
| Power | Power Type | DC-IN | ||
| Adapter | 12V/19V | |||
| Cooling | Heat-pipe + Smart Fan | |||
| Dimension | Construction | Metal | ||
| Mounting | YES | |||
| W x H x D | 240 x 174 x 28 mm | |||
| Environment | Operating Temp | 0~40℃ at 0.7m/s air flow | ||
| Storage Temp | -20~60℃ | |||
| Relative Humidity | 95%@40℃ (non-condensing) | |||
