| Processor | CPU | x6425E | J6412 |
| Frequency | 2.0GHz | 2.0GHz | |
| Turbo | 3.0GHz | 2.6GHz | |
| Cache | 1.5MB | 1.5MB | |
| BIOS | AMI EFI 64 Mbit | ||
| Memory | Type | 1*DDR4-3200MHz SO-DIMM | |
| Max. Capacity | 16 GB | ||
| Display | GPU | Intel® UHD Graphics (based on CPU) | |
| DP 1.2 | Max. 3840 x 2160 @60Hz | ||
| HDMI 1.4 | Max. 3840 x 2160 @30Hz | ||
| LVDS | Default 1920 x 1080 5V | ||
| eDP | Max. 4096 x 2304 @60Hz (co-design with LVDS, either one) | ||
| Audio | Controller | Realtek ALC897 | |
| Interface | Audio out + Mic in Combo, build-in amplifier 3W 8Ω | ||
| Ethernet | Controller | 2* intel i226 2.5Gigabit Ethernet, Wake-on-LAN | |
| Storage | SATA | 1 * SATA3 | |
| M.2 | 1 * M.2 2280 support SATA/PCIe SSD | ||
| Rear Panel | HDMI 1.4 | 1 | |
| DP 1.2 | 1 | ||
| LAN | 2 | ||
| USB3.1 | 4 | ||
| Audio | Audio out + Mic in Combo | ||
| DC-In | DC-in | ||
| Internal I/O | USB (2.54mm) | 2 x 9Pin USB2.0 expend to 4 x USB2.0 | |
| LVDS & Backlight | 1 x 24bit Dual Channel LVDS, 5V, 1920x1080 optional eDP | ||
| COM | 1 x 40Pin head expand 4*RS232 COM, 2 x 5Pin head (COM1, COM2), COM1、COM2 support RS232/RS485 by BIOS setting | ||
| Front Panel | 2 x 4pin | ||
| Speaker | 1 x 4pin | ||
| SATA Power | 1 x 4pin (2.0mm) | ||
| GPIO | 4Bit x DI, 4Bit x DO | ||
| Auto Power On | 1 x 2pin jumper | ||
| Expansion | M.2 #1 | 1 x M.2 2230 with Wi-Fi/BT module support | |
| M.2 #2 | 1 x M.2 2280, with SATA / PCIe SSD support | ||
| M.2 #3 | 1 x M.2 3042, with 4G / 5G support | ||
| OS | Windows 10/ 11, Linux | ||
| Functions | TPM, Watchdog, Auto Power On | ||
| Power | Power Type | DC-IN | |
| Adapter | 9-36V | ||
| Cooling | Fanless | ||
| Dimension | Form Factor | 146 x 102 mm | |
| Environment | Operating Temp | -20~60℃ at 0.7m/s air flow | |
| Storage Temp | -40~75℃ | ||
| Relative Humidity | 95%@40℃ (non-condensing) | ||
